Helicene synthesis by Brønsted acid-catalyzed cycloaromatization in HFIP [(CF₃)₂CHOH]

Introduction

Helicenes are a class of polycyclic aromatic hydrocarbons (PAH) that consist of ortho-fused aromatic rings arranged in a helical manner [1-6]. Since helicenes possess chirality derived from their helical structure, optically active helicenes and their derivatives exhibit characteristic properties, such as huge optical rotation [7], nonlinear optical effects [8-10], and circularly polarized light emission [11], which are rarely found in planar aromatic hydrocarbons (e.g., acenes and phenacenes). Therefore, the wide breadth of applications of helicenes as organic optical materials make them interesting synthetic targets.

Although several methods for the synthesis of helicenes have been reported, there are still specific problems in conducting these synthetic reactions for large scale production (Scheme 1). For example, the Mallory reaction [12], which is a widely used photocyclization in helicene synthesis [13,14], requires high dilution or excess amounts of oxidizing agents to suppress intermolecular side reactions (Scheme 1a). Diels–Alder (Scheme 1b) [15] and radical reactions (Scheme 1c) [16] directed toward helicene synthesis require high temperature conditions even for low to moderate yields. Olefin metathesis (Scheme 1d) [17] and alkyne trimerization (Scheme 1e) [18,19] require the use of expensive metal catalysts.

Recently, we have developed a Brønsted acid-catalyzed cycloaromatization in 1,1,1,3,3,3-hexafluoropropan-2-ol (HFIP) as solvent [20-22]. Fluoroalcohols, such as HFIP, exhibit high ionization power and low nucleophilicity, based on the electron-withdrawing inductive effect of fluorine, which helps to generate cations but does not affect cationic reactions [23-27]. Thus, HFIP greatly facilitates reactions via cationic intermediates [28]. In the presence of a catalytic amount of trifluoromethanesulfonic acid in HFIP, (biaryl-2-yl)acetoaldehydes or their acetal derivatives readily underwent intramolecular Friedel–Crafts-type C–C bond formation followed by dehydration or alcohol elimination, leading to the construction of benzene rings in the biaryl systems (Scheme 2) [20,21]. The reaction proceeded via oxocarbenium ion intermediates stabilized by HFIP. This method can be successfully applied to cyclization at multiple reaction sites. By using bisacetals bearing a naphthalene core (Ar²) as substrates, tandem cyclization achieved the efficient synthesis of several ortho-fused six-hexagon benzenoids [21].

On the basis of our work mentioned above, we assumed that this powerful cycloaromatization would be applicable to helicene synthesis. Thus, the following strategies were designed to establish a versatile method for the synthesis of helicenes (Scheme 3). Tandem cycloaromatization of bisacetals bearing a teraryl core was shown to be most effective for the one-shot construction of helicene frameworks. Based on ease of preparation, symmetrical cyclization precursors would be preferable, and thus they should possess either (i) one acetal moiety on each terminal aromatic ring (Ar²) of the teraryl core (Scheme 3, route a) or (ii) two acetal moieties on the central aromatic ring (Ar¹) (Scheme 3, route b). The teraryl structures were constructed by the formation of two C–C bonds via tandem Suzuki–Miyaura coupling of two terminal (Ar²) and central (Ar¹) arenes. It is noted that dihalogenated arenes were adopted as components for the central aromatic ring (Ar¹) in the teraryl structure, because the diborylated arenes were less available. Either (a) the coupling of boronic acid esters bearing one acetal moiety with dihalogenated arenes or (b) the coupling of dihalogenated arenes bearing two acetal moieties with arylboronic acids were conducted for the preparation of cyclization precursors. As described above, the tandem cycloaromatization of the obtained precursors proceeded via Friedel–Crafts-type bond formation followed by elimination, which enabled a rapid and efficient synthesis of helicenes, such as higher-order helicenes, double helical helicenes, and heterohelicenes.

Results and Discussion

Carbohelicenes such as [5]helicene (1a) and [6]helicene (1b) were synthesized via Suzuki–Miyaura coupling of readily available dihalogenated arenes 2 with phenylboronic acid ester 3 bearing a (1,3-dioxolan-2-yl)methyl group [29], followed by triflic acid-catalyzed cycloaromatization (Scheme 3, route a and Scheme 4a). Treatment of 1,2-dibromobenzene (2a) with 3 in the presence of a palladium catalyst with SPhos afforded o-terphenyl derivative 4a bearing two acetal groups in 96% yield (Scheme 4a). The obtained bisacetal 4a successfully underwent cycloaromatization in the presence of 17 mol % of TfOH in HFIP to afford [5]helicene (1a) in 90% yield. For the synthesis of [6]helicene, 1,8-diiodonaphthalene was adopted as the substrate for Suzuki–Miyaura coupling with 3 (Scheme 3, route a and Scheme 4b). In this coupling, SPhos was also effective in providing the bisacetal precursor 4b bearing a 1,8-diphenylnaphthalene framework in 45% yield despite high steric hindrance (Scheme 4b). Then, [6]helicene (1b) was obtained in 92% yield via cycloaromatization in the presence of 15 mol % of TfOH. It was noted that the gram-scale synthesis for both [5]- and [6]helicenes was possible, in which no serious decrease in yield was observed in Suzuki–Miyaura coupling and cycloaromatization (see the Experimental section) [30].

Next, double helical compounds were set as synthetic targets, because their unique optical properties have recently attracted much attention [5]. Herein, we synthesized two types of ortho-fused seven-hexagon benzenoids with two [4]helicene structures. According to the strategy illustrated in Scheme 3, route b, double helical helicenes 5 were synthesized using (naphthyl-1-yl)boronic acid (7) and dibromobenzenes 6 with two (1,3-dioxolan-2-yl)methyl groups, readily prepared from xylenes (Scheme 5). The Suzuki–Miyaura coupling of dibromobenzene 6a with 7 effectively proceeded to afford bisacetal 8a in 70% yield (Scheme 5a). Bisacetal 8a successfully underwent subsequent cycloaromatization in HFIP to afford S-shaped double helical helicene 5a in 90% yield. Similarly, C-shaped double helical helicene 5b was obtained in high yield using m-dibromobenzene 6b with two acetal moieties, prepared from m-xylene (Scheme 5b).

We also achieved the synthesis of heterohelicenes, which involve heteroatoms in the helicene frameworks, via a Suzuki–Miyaura coupling/cycloaromatization sequence (Scheme 3a, route a). Thus, hetero[4]-, [5]-, and [6]helicenes involving an oxygen, sulfur, or nitrogen atom were efficiently synthesized (Scheme 6). Hetero[4]helicenes 9 were synthesized via coupling of 3-bromobenzoheteroles 10, prepared from commercially available benzoheteroles, and subsequent cycloaromatization (Scheme 6a). Again, phenylboronic acid ester 3, used above in the synthesis of [5]- and [6]helicenes, was adopted as the coupling partner for 10. In the presence of a palladium catalyst, treatment of 3-bromobenzofuran (10a), 3-bromobenzothiophene (10b), and 3-bromo(N-tosyl)indole (10c) with 3 afforded the corresponding acetals 11a–c with 3-phenylbenzoheterole structures in 92%, 80%, and 93% yields, respectively. Acetals 11a–c successfully underwent TfOH-catalyzed cycloaromatization in HFIP to afford oxa-, thia-, and aza[4]helicenes 9a–c in 96%, 88%, and 93% yields, respectively. Thus, phenylboronic acid ester 3 bearing an acetal moiety functions as a reagent for fused naphthalene ring extension through our cross-coupling/cycloaromatization sequence [31-35].

Hetero[5]helicenes 12 were synthesized via tandem cycloaromatization using teraryl precursors, in which heterol rings were set as central aromatic rings (Ar¹) (Scheme 3, route a and Scheme 6b). As in the original strategy (Scheme 3, route a), coupling of 3,4-dibromofuran (13a), 3,4-dibromothiophene (13b), and 3,4-dibromo(N-tosyl)pyrrole (13c) with phenylboronic acid ester 3 bearing an acetal moiety proceeded to afford the corresponding bisacetals 14a–c in 53%, 76%, and 78% yields, respectively. The obtained bisacetals 14a–c efficiently underwent TfOH-catalyzed tandem cycloaromatization under appropriate conditions to afford oxa-, thia-, and aza[5]helicenes 12a–c in 90%, 90%, and 88% yields, respectively.

Furthermore, we demonstrated the synthesis of unsymmetrical thia[6]helicene 15 as a hetero[6]helicene synthesis (Scheme 6c). 3-Bromobenzothiophene 16 bearing a (1,3-dioxolan-2-yl)methyl group at the 2-position, which was readily prepared from benzothiophene, underwent Suzuki–Miyaura coupling with boronic acid ester 17 with a biphenyl structure and an acetal moiety, to afford bisacetal 18 in 92% yield. Thus, tandem cycloaromatization of 18 effectively proceeded to afford thia[6]helicene 15 in 63% yield.

Conclusion

In summary, we developed a facile and efficient method for the synthesis of several types of helicenes using a sequence of (i) Suzuki–Miyaura coupling of acetal-containing components and (ii) catalytic cycloaromatization with the aid of a cation-stabilizing fluoroalcohol, HFIP, as solvent. Particularly, helicene synthesis using tandem cyclization of bisacetals with teraryl structures is suitable for mass production of helicenes not only because multiple aromatic rings can be constructed at the same time but also because precursors can be easily prepared from commercially available compounds. Therefore, further progress can be made in applied research on helicenes as organic electronic materials, such as circularly polarized light emitting devices and nonlinear optical materials [7-11].

Experimental

¹H NMR and ¹³C NMR spectra were recorded on a Bruker Avance 500 or a JEOL ECS-400 spectrometer. Chemical shift values are given in ppm relative to internal Me₄Si (for ¹H NMR: δ = 0.00 ppm) and CDCl₃ (for ¹³C NMR: δ = 77.0 ppm).

Column chromatography and preparative thin-layer chromatography (PTLC) were conducted on silica gel (Silica Gel 60 N, Kanto Chemical Co., Inc. for column chromatography and Wakogel B-5F, Wako Pure Chemical Inductries for PTLC). N,N-Dimethylformamide (DMF) was purified by a solvent-purification system (GlassContour) equipped with columns of activated alumina and supported-copper catalyst (Q-5) before use. 1,1,1,3,3,3-Hexafluoropropan-2-ol (HFIP) was distilled from molecular sieves 4 Å and stored over activated molecular sieves 4 Å. 1,4-Dioxane was distilled from sodium and stored over activated molecular sieves 4 Å. 2-{2-[(1,3-Dioxolan-2-yl)methyl]phenyl}-4,4,5,5-tetramethyl-1,3,2-dioxaborolane (3) was prepared according to the literature procedure, and their spectral data showed good agreement with the literature data [21]. Unless otherwise noted, materials were obtained from commercial sources and used directly without further purification.

2,2''-Bis[(1,3-dioxolan-2-yl)methyl]-1,1':2',1''-terphenyl (4a)

A dioxane (6.6 mL) and H₂O (3.4 mL) solution of 1,2-dibromobenzene (2a, 471 mg, 2.00 mmol), boronate ester 3 (1.27 g, 4.39 mmol), Pd₂(dba)₃·CHCl₃ (52 mg, 51 μmol), SPhos (41 mg, 0.10 mmol), and K₃PO₄ (2.53 g, 11.9 mmol) was degassed by using the freeze-pump-thaw method three times. After stirring at 120 °C for 12 h, ethyl acetate and water were added to the mixture, and organic materials were extracted with ethyl acetate three times. The combined extracts were washed with brine and dried over Na₂SO₄. After removal of the solvent under reduced pressure, the residue was purified by silica gel column chromatography (hexane/EtOAc = 3:1) to give 4a (776 mg, 96%) as an orange oil.

¹H NMR (500 MHz, CDCl₃) δ 2.59 (dd, J = 14.4, 4.9 Hz, 0.8H), 2.70 (dd, J = 14.3, 5.3 Hz, 1.2H), 2.78–2.86 (m, 2H), 3.72–3.95 (m, 8H), 4.85–4.95 (m, 2H), 6.97–7.03 (m, 4H), 7.07–7.14 (m, 2H), 7.23–7.33 (m, 3.2H), 7.35–7.42 (m, 2.8H); ¹³C NMR (126 MHz, CDCl₃) δ 37.1, 37.7, 64.6, 64.73, 64.75, 104.5, 104.6, 125.4, 125.7, 126.8, 126.87, 126.91, 126.0, 129.5, 129.6, 130.0, 130.7, 131.2, 131.6, 133.8, 134.0, 140.2, 140.9, 141.4; IR (neat) ν: 3055, 3020, 2976, 2883, 1471, 1442, 1433, 1398, 1194, 1130, 1038, 1009, 943, 872, 837, 822, 752, 706, 621, 573, 538 cm⁻¹; HRMS (EI) m/z: [M]⁺ calcd. for C₂₆H₂₆O₄, 402.1826; found, 402.1815.

Gram-scale synthesis: Compound 4a was also prepared by the method described above using 1,2-dibromobenzene (2a, 1.47 g, 6.24 mmol), boronate ester 3 (3.99 g, 13.8 mmol), Pd₂(dba)₃·CHCl₃ (82 mg, 80 μmol), PPh₃ (84 mg, 0.32 mmol), K₃PO₄ (8.02 g, 37.8 mmol), dioxane (21 mL), and H₂O (10 mL) at 100 ºC for 6 h. Purification by silica gel column chromatography (hexane/EtOAc = 5:1) gave 4a (2.16 g, 86%).

[5]Helicene (1a)

In a similar manner as described in [20], trifluoromethanesulfonic acid (7.5 mg, 50 μmol) was added to an HFIP (0.9 mL) solution of bisacetal 4a (120 mg, 0.30 mmol) at 0 °C. After stirring at room temperature for 40 min, the reaction was quenched with phosphate buffer (pH 7). Organic materials were extracted with CH₂Cl₂ three times, and the combined extracts were washed with brine and dried over Na₂SO₄. After removal of the solvents under reduced pressure, the residue was purified by silica gel column chromatography (hexane/CH₂Cl₂ = 3:1) to give 1a (75 mg, 90%) as a white solid.

¹H NMR (500 MHz, CDCl₃) δ 7.23 (dd, J = 8.4, 7.1 Hz, 2H), 7.47 (dd, J = 7.9, 7.1 Hz, 2H), 7.80 (s, 2H), 7.81 (d, J = 8.5 Hz, 2H), 7.86 (d, J = 8.5 Hz, 2H), 7.90 (d, J = 7.9 Hz, 2H), 8.49 (d, J = 8.4 Hz, 2H); ¹³C NMR (126 MHz, CDCl₃) δ 124.3, 126.2, 126.3, 126.9, 127.2, 127.4, 127.8, 129.0, 130.7, 132.2, 132.5.

Gram-scale synthesis: Compound 1a was also synthesized by the method described above using bisacetal 4a (2.16 g, 5.37 mmol), trifluoromethanesulfonic acid (88 mg, 0.58 mmol), and HFIP (20 mL) at 0 °C for 40 min. Purification by silica gel column chromatography (hexane/EtOAc = 10:1) gave 1a (1.19 g, 80%).

1,8-Bis{2-[(1,3-dioxolan-2-yl)methyl]phenyl}naphthalene (4b)

A DMF (6.7 mL) and H₂O (3.3 mL) solution of 1,8-diiodonaphthalene (2b, 759 mg, 2.00 mmol), boronate ester 3 (1.28 g, 4.40 mmol), Pd₂(dba)₃·CHCl₃ (52 mg, 50 μmol), SPhos (42 mg, 0.10 mmol), and K₃PO₄ (2.54 g, 12.0 mmol) was degassed by using the freeze-pump-thaw method three times. After stirring at 90 °C for 10 h, ethyl acetate, hexane, and water were added to the mixture, and organic materials were extracted with an ethyl acetate–hexane (1:1) mixed solvent three times. The combined extracts were washed with brine and dried over Na₂SO₄. After removal of the solvent under reduced pressure, the residue was purified by silica gel column chromatography (toluene/EtOAc = 40:1) to give 4b (409 mg, 45%) as a white solid.

¹H NMR (500 MHz, CDCl₃) δ 2.36 (dd, J = 14.0, 6.1 Hz, 2H), 2.52 (dd, J = 14.0, 4.3 Hz, 2H), 3.62–3.83 (m, 8H), 4.65 (dd, J = 6.1, 4.3 Hz, 2H), 6.77–6.81 (m, 2H), 6.87–6.93 (m, 4H), 7.01–7.06 (m, 2H), 7.20 (dd, J = 7.0, 1.3 Hz, 2H), 7.46 (dd, J = 8.1, 7.0 Hz, 2H), 7.91 (dd, J = 8.3, 1.3 Hz, 2H); ¹³C NMR (126 MHz, CDCl₃) δ 38.9, 64.4, 64.7, 104.1, 124.8, 125.2, 126.8, 129.0, 129.05, 129.13, 129.9, 131.0, 133.8, 134.5, 138.8, 142.6; IR (neat) ν: 3053, 2966, 2883, 1489, 1396, 1132, 1043, 984, 831, 756 cm^–1; HRMS (APCI+) m/z: [M + H]⁺ calcd. for C₃₀H₂₉O₄, 453.2060; found, 453.2081.

Gram-scale synthesis: Compound 4b was also prepared by the method described above using 1,8-diiodonaphthalene (2b, 4.35 g, 11.4 mmol), boronate ester 3 (7.31 g, 25.2 mmol), Pd₂(dba)₃·CHCl₃ (301 mg, 0.29 mmol), SPhos (239 mg, 0.58 mmol), K₃PO₄ (14.6 g, 68.7 mmol), DMF (38 mL), and H₂O (19 mL) at 90 °C for 17 h. Purification by silica gel column chromatography (toluene/EtOAc = 40:1) gave 4b (2.05 g, 40%).

[6]Helicene (1b)

In a similar manner as described in [20]. To an HFIP (0.7 mL) solution of bisacetal 4b (91 mg, 0.20 mmol) was added trifluoromethanesulfonic acid (4.8 mg, 32 μmol) at 0 °C. After stirring at the same temperature for 40 min, the reaction was quenched with phosphate buffer (pH 7). Organic materials were extracted with ethyl acetate three times, and the combined extracts were washed with brine and dried over Na₂SO₄. After removal of the solvents under reduced pressure, the residue was purified by silica gel column chromatography (hexane/CH₂Cl₂ = 3:1) to give 1b (60 mg, 92%) as a yellow solid.

¹H NMR (500 MHz, CDCl₃) δ 6.66 (dd, J = 8.5, 7.4 Hz, 2H), 7.19 (dd, J = 7.9, 7.4 Hz, 2H), 7.58 (d, J = 8.5 Hz, 2H), 7.80 (d, J = 7.9 Hz, 2H), 7.89 (s, 4H), 7.93 (d, J = 8.1 Hz, 2H), 7.96 (d, J = 8.1 Hz, 2H); ¹³C NMR (126 MHz, CDCl₃) δ 124.0, 124.6, 125.5, 126.1, 126.8, 127.2, 127.5, 127.7, 127.8, 128.0, 129.9, 131.2, 131.7, 133.1.

Gram-scale synthesis: Compound 1b was also synthesized by the method described above using bisacetal 4b (2.05 g, 4.53 mmol), trifluoromethanesulfonic acid (173 mg, 1.2 mmol), and HFIP (15 mL) at 0 ºC for 3 h. Purification by silica gel column chromatography (hexane/CH₂Cl₂ = 3:1) gave 1b (1.31 g, 88%).
